Rail System 2″ (without rails) 39-0128

R14415,95

Z-Rail® Threaded Rail Systems, 1-1/4″ to 3″ Vertical Discharge
  • Sewage, storm water and effluent pump systems
  • For concrete, steel, or fiberglass tanks
  • Allows for removal of pumps from ground level
  • No confined space entry to service pump
  • No pull rods or hold down rods
  • Disconnect fitting with positive machine fit and o-ring seal provides a reliable seal
  • Seals up to 160 psi
  • Guide rails direct the pump to and from the disconnect fitting. Systems are supplied complete with disconnect fitting, guide plate, rail guide, and upper rail support bracket.
  • All systems use 3/4″ schedule 40 pipe rails (not included)
SKU: 39-0128 Category:

Description

Z-Rail® Threaded Rail Systems, 1-1/4″ to 3″ Vertical Discharge
  • Sewage, storm water and effluent pump systems
  • For concrete, steel, or fiberglass tanks
  • Allows for removal of pumps from ground level
  • No confined space entry to service pump
  • No pull rods or hold down rods
  • Disconnect fitting with positive machine fit and o-ring seal provides a reliable seal
  • Seals up to 160 psi
  • Guide rails direct the pump to and from the disconnect fitting. Systems are supplied complete with disconnect fitting, guide plate, rail guide, and upper rail support bracket.
  • All systems use 3/4″ schedule 40 pipe rails (not included)
Rail System 2″ (without rails) 39-0128
